Study of the effect of ignition crank angle and mixture composition on the performance of a spark-ignition engine fueled with ethanol
1
Department of Thermodynamics, Fluid Mechanics and Aircraft Propulsion, Lublin University of Technology, Poland
These authors had equal contribution to this work
Submission date: 2023-06-01
Final revision date: 2023-10-03
Acceptance date: 2023-11-06
Online publication date: 2024-01-10
Corresponding author
Karol Jan Ścisłowski
Department of Thermodynamics, Fluid Mechanics and Aircraft Propulsion, Lublin University of Technology, Nadbystrzycka 36, 20-618, Lublin, Poland
Department of Thermodynamics, Fluid Mechanics and Aircraft Propulsion, Lublin University of Technology, Nadbystrzycka 36, 20-618, Lublin, Poland
KEYWORDS
TOPICS
ABSTRACT
The publication presents the results of the measurements of the operating parameters of a spark-ignition engine fueled with 95-octane unleaded gasoline (ES95) and ethyl alcohol, approx. 92%. The measurements were carried out at a constant load: an engine speed of 1500 rpm and a constant pressure in the intake system – MAP = 0.45 bar. For each type of fuel, the measurements were carried out in two series for two variables. The ignition crank anglewas varied in the range of 0˚–40˚ and the mixture composition λ in the range of 0.85–1.25. The recorded engine performance parameters included torque, intake manifold pressure, intake air temperature, exhaust gas temperature and temporal fuel consumption; and exhaust gas composition was examined in terms of carbon monoxide, hydrocarbons and nitrogen oxides. The study showed that an ethanol-fueled engine has lower average efficiency compared to a gasoline one. The highest efficiency for ethanol was obtained for rich mixtures in the range λ = 0.85–1.0 and at high ignition advance angles. The use of alcohol fuel showed a very favorable effect on the composition of exhaust gas and a significantly lower content of harmful exhaust components was demonstrated. For the same operating points, carbon monoxide content was reduced by an average of 15%, and hydrocarbons and nitrogen oxides by an average of 80%.
REFERENCES (33)
1.
Andersen VF, Anderson JE, Wallington TJ, Mueller SA, Nielsen OJ. Vapor pressures of alcohol−gasoline blends. Energ Fuel. 2010;24(6):3647-3654. https://doi.org/10.1021/ef1002....
2.
Asad U, Kumar R, Zheng M, Tjong J. Ethanol-fueled low temperature combustion: a pathway to clean and efficient diesel engine cycles. Appl Energ. 2015;157:838-850. https://doi.org/10.1016/j.apen....
3.
Balat M, Balat H. Recent trends in global production and utilization of bio-ethanol fuel. Appl Energ. 2009;86(11):2273-2282. https://doi.org/10.1016/j.apen....
4.
Barbosa TP, Eckert JJ, Roso VR, Pujatti FJP, da Silva LAR, Horta Gutiérrez JC. Fuel saving and lower pollutants emissions using an ethanol-fueled engine in a hydraulic hybrid passengers vehicle. Energy. 2021;235:121361. https://doi.org/10.1016/j.ener....
5.
Chandran VGR, Tang CF. The impacts of transport energy consumption, foreign direct investment and income on CO2 emissions in ASEAN-5 economies. Renew Sust Energ Rev. 2013;24:445-453. https://doi.org/10.1016/j.rser....
6.
Czarnigowski J, Skiba K. The use of a low frequency vibration signal in detecting the misfire of a cylinder of an aircraft piston engine. SAE Technical Paper 2020-01-2023. 2020. https://doi.org/10.4271/2020-0....
7.
Czerwiński J, Comte P, Reutimann F, Mayer A. Influence of hydrous ethanol blends on particle emissions of small 2&4-stroke scooters. Part 1. Combustion Engines. 2011;144(1):29-36. https://doi.org/10.19206/CE-11....
8.
Elfasakhany A. State of art of using biofuels in spark ignition engines. Energies. 2021;14:779. https://doi.org/10.3390/en1403....
9.
Jakliński P, Czarnigowski J. An experimental investigation of the impact of added HHO gas on automotive emissions under idle conditions. Int J Hydrogen Energ. 2020;45(23):13119-13128. https://doi.org/10.1016/j.ijhy....
10.
Jakliński P, Czarnigowski J, Wendeker M. The effect of injection start angle of vaporized LPG on SI engine operation parameters. SAE Technical Paper 2007-01-2054. 2007. https://doi.org/10.4271/2007-0....
11.
Kanimozhi B, Kumar G, Alsehli M, Elfasakhany A, Veeman D, Balaji S et al. Effects of oxyhydrogen on the CI engine fueled with the biodiesel blends: a performance, combustion and emission characteristics study. Int J Hydrogen Energ. 2022;47(88):37668-37676. https://doi.org/10.1016/j.ijhy....
12.
Karthick C, Nanthagopal K, Ashok B, Saravanan SV. Influence of alcohol and gaseous fuels on NOx reduction in IC engines (chapter 12). NOx Emission Control Technologies in Stationary and Automotive Internal Combustion Engines. 2022. 347-385. https://doi.org/10.1016/B978-0....
13.
Keskin A. The influence of ethanol–gasoline blends on spark ignition engine vibration characteristics and noise emissions. Energ Source Part A. 2010;32(20):1851-1860. https://doi.org/10.1080/155670....
14.
Łomankiewicz D, Brodzik K, Bielaczyc P. GC-MS/FID analysis of aldehyde and hydrocarbon emissions from exhaust gases of a spark ignition engine fueled with different ethanol-gasoline blends. Combustion Engines. 2012;149(2):30-38. https://doi.org/10.19206/CE-11....
15.
Matla J. Possible applications of prechambers in hydrogen internal combustion engines. Combustion Engines. 2022;191(4):77-82. https://doi.org/10.19206/CE-14....
16.
Mohammed MK, Balla HH, Al-Dulaimi ZMH, Kareem ZS, Al-Zuhairy MS. Effect of ethanol-gasoline blends on SI engine performance and emissions. Case Studies in Thermal Engineering. 2021;25:100891. https://doi.org/10.1016/j.csit....
17.
Murcak A, Haşimoğlu C, Çevik İ, Karabektaş M, Ergen G. Effects of ethanol–diesel blends to performance of a DI diesel engine for different injection timings. Fuel. 2013;109:582-587. https://doi.org/10.1016/j.fuel....
18.
Pałuchowska M, Stępień Z, Żak G. The prospects for the use of ethanol as a fuel component and its potential in the reduction of exhaust emissions. Combustion Engines. 2014;158(3):80-92. https://doi.org/10.19206/CE-11....
19.
Pereirinha PG, González M, Carrilero I, Anseán D, Alonso J, Viera JC. Main trends and challenges in road transportation electrification. Transport Research Procedia. 2018;33:235-242. https://doi.org/10.1016/j.trpr....
20.
Peters JF, Burguillo M, Arranz JM. Low emission zones: Effects on alternative-fuel vehicle uptake and fleet CO2 emissions. Transport Res D-Tr E. 2021;95:102882. https://doi.org/10.1016/j.trd.....
21.
Pietrykowski K, Majczak A, Czarnigowski J. An electronically controlled hydrogen injector for Wankel engine. Combustion Engines. 2011;1-7.
22.
Reitz RD, Ogawa H, Payri R, Fansler T, Kokjohn S, Moriyoshi Y et al. IJER editorial: The future of the internal combustion engine. Int J Engine Res. 2019;21(1):3-10. https://doi.org/10.1177/146808....
23.
Saravanan P, Kumar NM, Ettappan M, Dhanagopal R, Vishnupriyan J. Effect of exhaust gas re-circulation on performance, emission and combustion characteristics of ethanol-fueled diesel engine. Case Studies in Thermal Engineering. 2020;20:100643. https://doi.org/10.1016/j.csit....
24.
Siadkowska K, Barański G, Sochaczewski R, Wendeker M. Experimental investigation on indicated pressure and heat release for direct hydrogen injection in a dual fuel diesel engine. Adv Sci Tech. 2022;16(3):54-66. https://doi.org/10.12913/22998....
25.
Stelmasiak Z, Pietras D. The evaluation of the regularity of the combustion process in the SI engine fueled with petrol and ethanol. Combustion Engines. 2017;168(1):94-99. https://doi.org/10.19206/CE-20....
26.
Ścisłowski K, Skiba K, Wendeker M, Kliza R, Siadkowska K, Lusiak T et al. Durability analysis of the prototype test rig for main rotors. Communications – Scientific Letters of the University of Zilina. 2022;24(2):B148-157. https://doi.org/10.26552/com.C....
27.
Taghizadeh-Alisaraei A, Rezaei-Asl A. The effect of added ethanol to diesel fuel on performance, vibration, combustion and knocking of a CI engine. Fuel. 2016;185:718-733. https://doi.org/10.1016/j.fuel....
28.
Wee J-H. Carbon dioxide emission reduction using molten carbonate fuel cell systems. Renew Sust Energ Rev. 2014;32:178-191. https://doi.org/10.1016/j.rser....
29.
Yu F, Yu B. The use of ethanol–gasoline blend as a fuel in an SI engine. Renew Energ. 2004;29:1181-1191. https://doi.org/10.1016/j.rene....
30.
Zacharewicz M, Kniaziewicz T. Model tests of a marine diesel engine powered by a fuel-alcohol mixture. Combustion Engines. 2022;189(2):83-88. https://doi.org/10.19206/CE-14....
31.
Zangoei S, Salehnia N, Khodaparast Mashhadi M. A comparative study on the effect of alternative and fossil energy consumption on economic growth and foreign direct investment in selected countries using SUR approach. Environ Sci Pollut R. 2021;28(16):19799-19809. https://doi.org/10.1007/s11356....
32.
Zapata C, Nieuwenhuis P. Exploring innovation in the automotive industry: new technologies for cleaner cars. J Clean Prod. 2010;18(1):14-20. https://doi.org/10.1016/j.jcle....
33.
Zhang B, Liu H. Theoretical prediction model and experimental investigation of detonation limits in combustible gaseous mixtures. Fuel. 2019;258:116132. https://doi.org/10.1016/j.fuel....
