A mathematical study of the narrowband lambda sensor characteristics for lean and rich operation
More details
Hide details
1
Faculty of Mechanical Engineering, Wrocław University of Science and Technology, Poland
Submission date: 2025-06-17
Final revision date: 2025-07-07
Acceptance date: 2025-07-22
Online publication date: 2025-11-16
Corresponding author
Adam Kamiński
Vehicle Engineering, Wrocław University of Science and Technology, Poland
KEYWORDS
TOPICS
ABSTRACT
The study includes attempts to identify separate mathematical functions for the rich and lean sides of a narrowband lambda sensor, with the goal of applying an algorithm to estimate the actual Air-Fuel Ratio (AFR) in a range other than stoichiometric. Subsequently, the aim is to force the engine\'s Powertrain Control Module (PCM) to operate in closed-loop mode at an AFR different from 1. A key aspect of the study is the use of a conventional narrowband lambda sensor, typically installed in older internal combustion engines. This approach could, for example, enable retrofitting of older engines or adapting them to operate on alternative fuels. The study also illustrates the physical characteristics of the sensor’s heater, aiming to optimize the algorithm for maintaining a stable sensor temperature, thereby improving reading accuracy and control quality
REFERENCES (15)
1.
Aravind S, Ragupathi P, Kumar DS, Vignesh G. A numerical investigation of automotive lambda sensor to improve the life span of the sensor using CFD. IOP Conf Ser Mater Sci Eng. 2020;923(1).
https://doi.org/10.1088/1757-8....
2.
Bosch Engineering GmbH, Lambda Sensor LSU 4.9 datasheet, 51865867 en, 1, 26. Aug. 2025.
3.
Collings N, Harris JA, Glover K. Estimating IC engine exhaust gas lambda and oxygen from the response of a universal exhaust gas oxygen sensor. Meas Sci Technol. 2013;24(9):095101.
https://doi.org/10.1088/0957-0....
4.
Hills B. United States Patent Preparing Fire-Fighting Concentration US 4,464,267 1984;(19).
6.
Jakliński P, Czarnigowski J, Ścisłowski KJ. Study of the effect of ignition crank angle and mixture composition on the performance of a spark-ignition engine fueled with ethanol. Combustion Engines. 2024;197(2):56-63.
https://doi.org/10.19206/CE-17....
7.
Klett S, Piesche M, Heinzelmann S, Weyl H, Wiedenmann H, Schneider U et al. Numerical and experimental analysis of the momentum and heat transfer in exhaust gas sensors. SAE Technical Paper 2005-01-0037. 2005.
https://doi.org/10.4271/2005-0....
8.
Moos R, Izu N, Rettig F, Reiß S, Shin W, Matinfara I. Resistive oxygen gas sensors for harsh environments. Sensors. 2011;11(4):3439-3465.
https://doi.org/10.3390/s11040....
9.
Nishiyama A, Ikeda Y, Serizawa T. Lean limit expansion up to lambda 2 by multi-point microwave discharge igniter. 2018;247-260. Ignition Systems for Gasoline Engines: 4th International Conference December 6–7, 2018, Berlin.
https://doi.org/10.5445/IR/100....
13.
Toema M. Physics-based characterization of lambda sensor output to control emissions from natural gas fueled engines. An Abstract of a Disertation, Kansas State University, 2010.
14.
Tutunea D, Dumitru I, Stănciuc-Oţăt OV. Overview of the use of oxygen sensors in automotive applications. IOP Conf Ser Mater Sci Eng. 2024;1303(1):012014.
https://doi.org/10.1088/1757-8....
15.
Urbański B, Przybyła G, Brodziński Ł, Savitskaya M. Reducing emissions of harmful substances in rally cars. Combustion Engines. 2024;197(2):132-8.
https://doi.org/10.19206/CE-18....
