Effects of torch flame strength on the combustion process in medium-speed gas engines through pre-chamber orifice specifications
1
, Japan
Submission date: 2025-01-05
Final revision date: 2025-05-25
Acceptance date: 2025-05-27
Online publication date: 2025-07-10
Corresponding author
Takuya Wakasugi
Interdisciplinary Graduate School of Engineering Sciences (IGSES), Kyushu University, Japan
Interdisciplinary Graduate School of Engineering Sciences (IGSES), Kyushu University, Japan
KEYWORDS
TOPICS
ABSTRACT
Gas engines are eagerly introduced for the moment to reduce GHG emissions from the marine sector and could be used by green methane from the methanation process in the future. Pre-chamber-type gas engines burning lean premixture in a main chamber are the mainstream in a medium-speed engine range. Although the ejection behaviour of torch flames from the pre-chamber has a significant impact on the combustion in the main chamber, there are few research examples of confirming the effects of the pre-chamber specifications by actual observation of the combustion process. In this study, a constant-volume combustion vessel was prepared to reproduce the combustion chamber near the top dead centre of a medium-speed gas engine, to visualize its whole combustion chamber, and to investigate the effects of the pre-chamber specifications. The validity of the CFD simula-tion based on the RANS turbulence model and the possibility of a design index for the ejec-tion strength of torch flames were also examined.
REFERENCES (29)
1.
Aakko-Saksa T, Lehtoranta K, Kuittinen N, Järvinen A, Jalkanen J, Johnson K et al. Reduction in greenhouse gas and other emissions from ship engines: current trends and future options. Prog Energ Combust. 2023;94:101055. https://doi.org/10.1016/j.pecs....
2.
Al-Enazi A, Okonkwo EC, Bicer Y, Al-Ansari T. A review of cleaner alternative fuels for maritime transportation. Energy Reports. 2021;7:1962-1985. https://doi.org/10.1016/j.egyr....
3.
Aoyagi T, Wakasugi T, Tsuru D, Tashima H. Analysis of effects of pre-chamber orifices on torch flame behaviours in lean-burn gas engines. Combustion Engines. 2024;199(4):3-14. https://doi.org/10.19206/CE-18....
4.
Babajimopoulos A, Assanis DN, Flowers DL, Aceves SM, Hessel RP. A fully coupled computational fluid dynamics and multi-zone model with detailed chemical kinetics for the simulation of premixed charge compression ignition engine. Int J Engine Res. 2005;6:497-512. https://doi.org/10.1243/146808....
5.
Brynolf S, Hansson J, Anderson JE, Skov IR, Wallington TJ, Grahn M et al. Review of electrofuel feasibility – prospects for road, ocean, and air transport. Prog Energ. 2022;4:4. https://doi.org/10.1088/2516-1....
6.
Bueschke W, Skowron M, Szwajca F, Wisłocki K. Flame propagation velocity in 2-stage gas combustion system applied in SI engine. IOP Conf Ser: Mater Sci Eng. 2018; 421:042009. https://doi.org/10.1088/1757-8....
7.
Bueschke W, Skowron M, Wisłocki K, Szwajca F. Comparative study on combustion characteristics of lean premixed CH4/air mixtures in RCM using spark ignition and turbulent jet ignition in terms of orifices angular position change. Combustion Engines. 2019;176(1):36-41. https://doi.org/10.19206/CE-20....
8.
Cho HM, He BQ. Spark ignition natural gas engines – a review. Energ Convers Manage. 2007;48(2):608-618. https://doi.org/10.1016/j.enco....
9.
Duan X, Deng B, Liu Y, Zou S, Liu J, Feng R. An experimental study the impact of the hydrogen enrichment on cycle-to-cycle variations of the large bore and lean burn natural gas spark-ignition engine. Fuel. 2020;282:118868. https://doi.org/10.1016/j.fuel....
10.
Einewall P, Johansson B. Cylinder to cylinder and cycle to cycle variations in a six cylinder lean burn natural gas engine. SAE Technical Paper 2000-01-1941. 2000. https://doi.org/10.4271/2000-0....
11.
Guo H, Zhou S, Shreka M, Feng Y. Effect of pre-combustion chamber nozzle parameters on the performance of a marine 2-stroke dual fuel engine. Processes. 2019;7(12):876. https://doi.org/10.3390/pr7120....
13.
Ishibashi R, Tsuru D. An optical investigation of com-bustion process of a direct high-pressure injection of natural gas. J Mar Sci Technol. 2017;22:447-458. https://doi.org/10.1007/s00773....
14.
Kazakov A, Frenklach M. GRI-Mech. University of California at Berkeley. http://combustion.berkeley.edu /drm/.
15.
Korakianitis T, Namasivayam AM, Crookes RJ. Natural-gas fueled spark-ignition (SI) and compression-ignition (CI) engine performance and emissions. Prog Energ Combust. 2011;37(1):89-112. https://doi.org/10.1016/j.pecs....
16.
Kulzer AC. Sustainability & powertrain systems: from electrification to hydrogen and efuels (updated). Proc JSAE PEL Int Meeting, Technical Challenges for a Carbon Neutral Society by 2050. Keynote 4, Kyoto 2023.
17.
Liu J, Ulishney CJ, Dumitrescu CE. Experimental inves-tigation of a heavy-duty natural gas engine performance operated at stoichiometric and lean operations. Energ Convers Manage. 2021;243(x):114401. https://doi.org/10.1016/j.enco....
18.
Liu L, Wu Y, Wang Y. Numerical investigation on knock characteristics and mechanism of large-bore natural gas dual-fuel marine engine. Fuel. 2022;310:122298. https://doi.org/10.1016/j.fuel....
19.
Nada Y, Kidoguchi Y, Yamashita Y, Furukawa R, Kaya R, Nakamo H et al. Effects of sub-chamber configuration on heat release rate in a constant volume chamber simulating lean-burn natural gas engines. SAE Int J Adv & Curr Prac in Mobility. 2020;2(2):1032-1040. https://doi.org/10.4271/2019-3....
20.
Pielecha I. Analysis of mass transfer in marine engine with prechamber combustion spark ignition system. Bull Pol Ac: Tech. 2021;69(2):e136744. https://doi.org/10.24425/bpast....
21.
Pielecha I, Bueschke W, Skowron M, Fiedkiewicz Ł, Szwajca F, Cieślik W et al. Prechamber optimal selection for a two stage turbulent jet ignition type combustion system in CNG-fuelled engine. Combustion Engines. 2019;176(1):16-26. https://doi.org/10.19206/CE-20....
22.
Senecal PK, Pomraning E, Richards KJ, Briggs TE, Choi CY, McDavid RM et al. Multi-dimensional modeling of direct-injection diesel spray liquid length and flame lift-off length using CFD and parallel detailed chemistry. Journal of Engines. 2003;112(3):1331-1351. http://www.jstor.org/stable/44....
23.
Shapiro E, Tiney N, Kyrtatos P, Kotzagianni M, Bolla M, Boulouchos K et al. Experimental and numerical analysis of pre-chamber combustion systems for lean burn gas engines. SAE Technical Paper 2019-01-0260. 2019. https://doi.org/10.4271/2019-0....
24.
Shi J, Zhu Y, Feng Y, Yang J, Xia C. A prompt decarbonization pathway for shipping: green hydrogen, ammonia, and methanol production and utilization in marine engines. Atmosphere. 2023;14(3):584. https://doi.org/10.3390/atmos1....
25.
Tashima H, Kunimitsu M, Sugiura K, Tsuru D. Development of high-efficiency gas engine through observation and simulation of knocking phenomena. Proc CIMAC Congress 10 Bergen. 2013; No. 213.
26.
Validi AA, Schock H, Jaberi F. Turbulent jet ignition assisted combustion in a rapid compression machine. Combust Flame. 2017;186:65-82. https://doi.org/10.1016/j.comb....
27.
Wakasugi T, Tsuru D, Tashima H. Influences of the pre-chamber orifices on the combustion behavior in a constant volume chamber simulating pre-chamber type medium-speed gas engines. Combustion Engines. 2022;191(4):66-76. https://doi.org/10.19206/CE-14....
28.
Yasueda S, Takasaki K, Tashima H. The abnormal com-bustion affected by lubricating oil ignition in premixed gas engine. Proc ASME 2012 ICES. 2012:29-36. https://doi.org/10.1115/ICES20....
29.
Yuan M, Thellufsen JZ, Lund H, Liang Y. The electri-fication of transportation in energy transition. Energy. 2021;236:121564. https://doi.org/10.1016/j.ener....
