Conversion to hydrogen fueling of a range extender SI engine of a 48 V hybrid electric vehicle
1
Department of Automotive Vehicles, Cracow Univertsity of Technology, Poland
These authors had equal contribution to this work
Submission date: 2025-06-19
Final revision date: 2025-08-15
Acceptance date: 2025-08-25
Online publication date: 2025-09-18
Corresponding author
Marcin Noga
Department of Automotive Vehicles, Cracow Univertsity of Technology, Jana Pawla II 37, 31-864, Kraków, Poland
Department of Automotive Vehicles, Cracow Univertsity of Technology, Jana Pawla II 37, 31-864, Kraków, Poland
KEYWORDS
TOPICS
ABSTRACT
The purpose of the article is to present further development stages of the range extender designed for a 48 V electric vehicle. The initial design of the system consisted of a 160 cc single-cylinder carbureted gasoline engine coupled to a synchronous 3-phase AC generator. The conversion of the engine included an adaptation of a port hydrogen injection with astand-alone engine management system. The research was focused on engine calibration first of all in order to achieve its stable operation avoiding abnormal combustion when running on hydrogen. In addition to the basic engine performance indicators, the composition of exhaust gases emitted by the engine was also measured. Initial tests proved the conversion to be stable and the range extender reaches efficiency sligtly higher to achieved when the engine was fueled by gasoline.
REFERENCES (22)
1.
Antila M, Galimova T, Breyer C, Norouzi S, Repo S, Pihlatie M et al. Future energy technology for nonroad mobile machines. Adv. Energy Sustainability Res. 2025;6:2400257. https://doi.org/10.1002/aesr.2....
2.
Borghi M, Mattarelli E, Muscoloni J, Rinaldini CA, Savioli T, Zardin B. Design and experimental development of a compact and efficient range extender engine. Appl Energ. 2017;202:507-526. https://doi.org/10.1016/j.apen....
3.
Brito FP, Martins J, Lopes F, Castro C, Martins L, Moreira ALN. Development and assessment of an over-expanded engine to be used as an efficiency-oriented range extender for electric vehicles. Energies. 2020;13(2):430. https://doi.org/10.3390/en1302....
4.
Dingel O, Mayrock M, Peteranderl C. CNG Range extender for an electrically driven garbage collection vehicle. ATZ Heavy Duty worldwide. 2021;14(1):20-5. https://doi.org/10.1007/s41321....
5.
Kęska A, Dziubek M, Michalik D. The economic aspects of vehicle operation in the context of electromobility strategies. Combustion Engines. 2024;196(1):146-152. https://doi.org/10.19206/CE-17...
6.
Kim S, Lee J, Lee S, Lee S, Kim K, Min K. Effects of various compression ratios on a direct injection spark ignition hydrogen-fueled engine in a single-cylinder engine. Int J Automot Technol. 2024;25(5):1159-72. https://doi.org/10.1007/s12239....
7.
Kordzinski C, Papuga T, Rudkowski M. Electronically controlled fuel supply system of hydrogen spark ignition engines. Advances in Hydrogen Energy. V Proceedings of the 5th World Hydrogen Energy Conference, Toronto, 15-20 July 1984. 4:1649-1654.
8.
Lei J, Niu J, Tian G, Xin G, Yang X, Shi C. Advances in hydrogen as a zero-carbon fuel for rotary engines: a review. Fuel. 2025;381:133681. https://doi.org/10.1016/j.fuel....
9.
Lemmon EW, Huber ML, Leachman JW. Revised standardized equation for hydrogen gas densities for fuel consumption applications. J Res Natl Inst Stand Technol. 2008;113(6):341. https://doi.org/10.6028/jres.1....
10.
Leroux C, Böwing R, Hochfilzer B, Zuschnig A, Behr M. Hydrogen in the gas network – challenges and solutions for high performance engines for power generation. In: Heintzel A. Heavy-Duty-, on- und Off-Highway-Motoren 2022 Stand der Energiewende im Heavy-Duty-Bereich. Springer Vieweg. 2023:143-157. https://doi.org/10.1007/978-3-....
11.
Noga M, Gorczyca P, Hebda R. The effects of use of the range extender in a small commercial electric vehicle. AE. 2020;4(1):5-19. https://doi.org/10.31603/ae.41....
12.
Noga M, Moskal T. Hydrogen and ethanol co-combustion in a SI engine for CO2 emission reduction. Proceedings of 28th International Scientific Conference. Transport Means. 2024;1:981-986. https://doi.org/10.5755/e01.23....
13.
Pielecha I. Control algorithms for a range extender vehicle with an combustion engine. Combustion Engines. 2020;183(4):3-10. https://doi.org/10.19206/CE-20....
14.
Ruíz-Domínguez JJ, Trejo-Valdez MD, Grave-Capistrán MA, Torres-SanMiguel CR. Experimental assessment of hydrogen combustion cells in a four-stroke engine. In: Carbone G, Quaglia G. Proceedings of I4SDG Workshop 2025 - IFToMM for Sustainable Development Goals Volume 2. Springer; 2025.559-568. https://doi.org/10.1007/978-3-....
15.
Skarlis S, Molos T, Ayfantopoulou G, Nikiforiadis A, Bakouros L. Light commercial electric vehicles with hydrogen fuel-cell range extender: refueling strategy evaluation. Research in Transportation Business & Management. 2023;50:101040. https://doi.org/10.1016/j.rtbm....
16.
Sutkowski M, Mareczek M. Operational experience and new developments for industrial gas engines fuelled with hydrogen fuels. Combustion Engines. 2024;197(2):146-151. https://doi.org/10.19206/CE-18....
17.
Szwaja S. Combustion pressure fluctuations study in the hydrogen fueled internal combustion engine (in Polish). Częstochowa University of Technology Publishing House. Częstochowa 2010.
18.
Tran M, Bhatti A, Vrolyk R, Wong D, Panchal S, Fowler M et al. A review of range extenders in battery electric vehicles: current progress and future perspectives. WEVJ. 2021;12(2):54. https://doi.org/10.3390/wevj12....
19.
Wu L, Feng H, Zhang Z, Jia B, Wang J, Yang F et al. Experimental analysis on the operation process of opposed-piston free piston engine generator. Fuel. 2022;325:124722. https://doi.org/10.1016/j.fuel....
20.
Wu Z, Han Z, Shi Y, Liu W, Zhang J, Huang Y et al. Combustion optimization for fuel economy improvement of a dedicated range-extender engine. P I Mech Eng D-J Aut. 2021;235(9):2525-39. https://doi.org/10.1177/095440....
21.
Zambalov SD, Yakovlev IA, Maznoy AS. Effect of multiple fuel injection strategies on mixture formation and combustion in a hydrogen-fueled rotary range extender for battery electric vehicles. Energ Convers Manage. 2020;220:113097. https://doi.org/10.1016/j.enco....
22.
Zhang C, Xu Z, Wang Y, Liu L. Development of a hydrogen free-piston engine generator for range extenders. Sustainable Energy Technologies and Assessments. 2024;65:103788. https://doi.org/10.1016/j.seta....
